R-RP1300 standard wide belt sander for wood flat board without paint

R-RP1300 standard wide belt sander for wood flat board without paint

    • R-RP1300 standard wide belt sander for wood flat board without paint
    • R-RP1300 standard wide belt sander for wood flat board without paint
    • R-RP1300 standard wide belt sander for wood flat board without paint
  • R-RP1300 standard wide belt sander for wood flat board without paint

    Product Details:

    Place of Origin: Shandong, China
    Brand Name: KCARPENTER
    Certification: ISO,CE
    Model Number: R-RP1300

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 SET
    Price: 4000-15000usd/set
    Packaging Details: Plywood box
    Delivery Time: 15 days
    Payment Terms: TT/ LC
    Supply Ability: 50set/month
    Contact Now
    Detailed Product Description

    R-RP1300 standard wide belt sander for wood flat board without paint

    Product features:

    • This machine is suitable for furniture, floor, integrated material,wooden structure, bamboo, wood board and so on.
    • Accurate thickness gauge display, adjust the processing thickness.
    • Large diameter eccentric sanding roller, large amount of sand, power enough, can adjust the lifting and light pad.
    • Variable frequency speed feeding system.
    • Clean brush, medium and soft, clean the dust on the surface of the workpiece.
    • Full abrasion resistant roller structure.
    • Any combination of sand head, effective grinding of various substrates.
    Model R-RP1300
    Max .working width 1300mm
    Min. Working length 500mm
    Max .working thickness 3-110mm
    Speed of conveyor 6-30m/min
    Total motor power 63.37kw
    No.1 abrasive belt power 37kw
    No.2 abrasive belt power 22kw
    Power of conveyor belt 4kw
    Power of lifting 0.37kw
    Diameter of No.1 abrasive belt 240mm
    Diameter of No.2 abrasive belt 210mm
    Size of abrasive belt 1330*2200mm
    Working pressure 0.6Mpa
    Consumption of Compressed air 9600m³/h
    Overall dimensions 2700*2100*2100mm
    Net weight 3300KG



    R-RP1300 standard wide belt sander for wood flat board without paint

    R-RP1300 standard wide belt sander for wood flat board without paint

    R-RP1300 standard wide belt sander for wood flat board without paintR-RP1300 standard wide belt sander for wood flat board without paintR-RP1300 standard wide belt sander for wood flat board without paint

    R-RP1300 standard wide belt sander for wood flat board without paint
